Yucoo 1000w inverter solar hybrid 30a mppt solar charge controller 24v

USD275-308

Charging Current

30A

Output Voltage

Inverter mode: 110VAC/220VAC±5％

Input Voltage

110V:85~138VAC;220V:170~275VAC

Customization

Customized logo (Min. Order: 300 Sets)

Customized packaging (Min. Order: 300 Sets)

Graphic customization (Min. Order: 300 Sets)

Protection

Trade Assurance

On-time Dispatch Guarantee

Refund Policy

Product Details

Quick Details

Product Description

— Touch screen display

— Various protection functions

— Automatic switch working modes

— Ring transformer based with low consumption

— Low frequency, pure sine wave output, hybrid off grid.

— Options: Built in SPD , WIFI module remote control and monitoring

— Faster installation and commissioning with a simple user interface

— LVD , HVD , charging voltage and turn off voltage settable

— Built-in MPPT solar charger

Product Parameters

Model	YK-IM1000
Rated Power	1000W
Battery Voltage (V)	24V
Charging Current	Max 30A
AC Input Range	110V:85~138VAC;220V:170~275VAC
Input Frequency Range	50HZ:46HZ~54HZ;60HZ:55HZ~65HZ
Output Voltage	Inverter mode: 110VAC/220VAC±5％
Output Frequency Range	Inverter mode: 50HZ/60HZ±1HZ
Output Waveform	Pure sine wave
Switching Time	<;;;;;;;10ms
Inverter Efficiency	>;;;;;;;85%
Overload	110~120%/30s;>;;;;;;;160%/3s
Protection	Battery overvoltage and low voltage protection, overload protection short circuit protection, over temperature protection
Display	LCD+LED
Cooling Method	Forced air cooling
Operating Temperature	0~40℃
Controller MPPT
Rated Current	30A
DC Voltage	24V
Max PV power	750W
Max Voltage	150V
Dimensions	490350200mm
Package Size	550390240mm
N.W.	14KG
