  • Yucoo CE RoHS approved 12V to 5V 3A dc to dc step down buck converter 15W
  • Move the mouse over the graph to enlarge the picture
  • Yucoo CE RoHS approved 12V to 5V 3A dc to dc step down buck converter 15W Yucoo CE RoHS approved 12V to 5V 3A dc to dc step down buck converter 15W Yucoo CE RoHS approved 12V to 5V 3A dc to dc step down buck converter 15W

Yucoo CE RoHS approved 12V to 5V 3A dc to dc step down buck converter 15W

USD 4-5.1

  • Input Voltage
  • 12Vdc(8-22Vdc)
  • Output Voltage
  • 5Vdc
  • Output Power
  • 15W
  • Customization
  • Customized logo (Min. Order: 300 Sets)

    Customized packaging (Min. Order: 300 Sets)

    Graphic customization (Min. Order: 300 Sets)

  • Protection
  • Trade Assurance

    On-time Dispatch Guarantee

    Refund Policy

  • Product Details

    Quick Details

    Product Name:
    DC DC Converter
    Input voltage:
    12V (8-22V)
    Output voltage:
    5V
    Current:
    3A
    Certificate:
    CE ROHS
    Protections:
    Over-current / voltage / load/temperature protection
    Warranty:
    1 year
    Working temperature:
    -40°c ~ +80°c
    Working humidity:
    10% ~ 90%
    Size:
    46*27*14mm


    Product Description

    1. 100% full power & stable current output
    2. 100% Imported components
    3. Wide input voltage from 8-12Vdc
    4. 100% waterproof & anti-shock protection, Ultra compact size, light weight
    5. Industry grade step-down converter, efficiency up to 90%
    6. Waterproof level: IP68
    7. According CE(EN61000) / RoHS design
    8. Die-cast aluminum shell, epoxy potting, Cooling by free air convection,
    9. Protections: Over-current, Over-temperature, and Short-circuit,
    Auto-recovery when device is back to normal operating
    10. Non-Isol
    ated Module

    11. 1 year warranty

    Product Parameters

    Product name
    DC DC Converter
    Model
    YK-DD12S503
    Input Voltage12VDC
    Voltage range8~12 VDC
    Output Voltage5 VDC
    Output Current3 Amps
    Output Power15 Watts
    Effciency90%
    Working temperature-35℃~+80℃
    Weight50G
    Size46*27*14MM
    Installation length13-15cm


    Details Images



    Recommend Products Range

    BUCK DC-DC CONVERTER MODEL LIST
    Model SeriesInput-VOutput-VOutput Current
    YK-DD1224S5**12V/24V5v3A|5A|10A|15A|20A|30A|40A|50A|60A
    YK-DD24S12**24v12v1.5A|3A|5A|8A|10A|15A|20A|30A|40A|50A|60A|85A|100A
    YK-DD24S13.8**24v13.8V
    5A|10A|15A|20A|30A|40A|50A|60A
    YK-DD24S19**24V19V5A|10A|15A
    YK-DD36S12**36V12V5A|10A|15A|20A|30A|50A|60A
    YK-DD48S5**48V5V5A|10A|15A|20A
    YK-DD48S12**48V12V5A|10A|15A|20A|30A|40A|50A|60A
    YK-DD48S13.8**48V13.8V5A|10A|15A|20A|30A|40A|50A|60A
    YK-DD48S19**48V19V5A|8A|10A
    YK-DD48S24**48V24V3A|5A|10A|15A|20A|30A|40A|50A
    YK-DD60S12**60V12V5A|10A|15A
    YK-DD60S24**60V24V5A|10A
    BOOST DC-DC CONVERTER MODEL LIST
    Model SeriesInput-VOutput-VOutput Current
    YK-DD12S24**12V24V1A|2A|3A|5A|8A|10A|15A|20A|25A|30A|40A|50A
    YK-DD12S19**12V19V5A|8A|10A|15A|20A
    YK-DD12S28**12V28V3A|5A|8A|10A|15A|20A|25A|30A|40A
    YK-DD12S48**12V48V1A|2A|3A|4A|8A|10A|15A|20A
    YK-DD24S48**24V48V3A|5A|10A|20A|30A|40A
    YK-DD24S36**24V36V5A
    BUCK& BOOST DC-DC CONVERTER MODEL LIST
    Model SeriesInput-VOutput-VOutput Current
    YK-DD12S12**8-40V12V1A|2A|3A|5A|6A|10A|15A|20A|25A
    YK-DD12S13.8**8-40V13.8V3A|5A|10A|15A|20A|25A
    YK-DD24S24**9-40V24V2A|3A|4A|6A|10A|15A
